Asahi Sion Black 0.014 Inch Guide Wire Straight Tip 190cm APW14R010S

Asahi Sion Black 0.014 Inch Guide Wire Straight Tip 190cm APW14R010S is a coronary guide wire designed for navigation during interventional procedures. It features a straight tip, 0.014-inch diameter, and 190 cm usable length for controlled vessel tracking. Its polymer and hydrophilic coating supports smooth advancement through tortuous coronary anatomy.

BUY NOW

SKU APW14R010S-2 Category

The Sion Black is designed to provide a balance of flexibility, trackability, and support during coronary interventions. Its polymer jacket helps facilitate smooth lesion entry and navigation through curved vessel anatomy. The hydrophilic coating provides lubricity to support controlled guide wire advancement during the procedure. Its 12 cm coil and 3 cm radiopaque segment support distal flexibility and fluoroscopic visualization.

Technical Specification

Specification Details
Product Name ASAHI SION black
Catalog Number APW14R010S
Tip Shape Straight
Usable Length 190 cm
Outer Diameter 0.36 mm (0.014″)
Tip Load 0.8 gf
Coating Polymer + Hydrophilic
Radiopaque Length 3 cm

Product Also Known As

Asahi Sion Black Guide Wire, Sion Black 0.014 Inch Guide Wire, Sion Black 190cm Guide Wire, APW14R010S Guide Wire, Asahi Sion Black Straight Tip Guide Wire, Sion Black Coronary Guide Wire
