Asahi sion blue guide wire straight tip 190cm AHW14R104S

ASAHI SION Blue Guide Wire Straight Tip AHW14R104S is a single-use hybrid-coated coronary guide wire designed for navigating tortuous coronary anatomy during percutaneous coronary intervention (PCI). It features a straight 0.014″ tip with exceptional torque response, flexibility, and device support for reliable lesion crossing. The 190 cm working length is ideal for routine coronary interventional procedures.

BUY NOW

SKU AHW14R104S Category

The ASAHI SION Blue Guide Wire Straight Tip AHW14R104S is engineered to provide excellent steerability and enhanced device delivery during routine and complex coronary interventions. Its proprietary ACT ONE composite core technology delivers superior torque transmission and shape retention, while the hybrid coating combines a hydrophilic shaft with a hydrophobic tip to ensure smooth vessel navigation and precise control. The soft 0.5 gf straight tip, 20 cm spring coil, and 3 cm radiopaque segment enhance atraumatic vessel access, fluoroscopic visibility, and support for device delivery through challenging coronary anatomy. Supplied sterile for single-use applications, the guide wire delivers dependable clinical performance while eliminating the need for reprocessing.

Technical Specification

Specification Details
Model Number AHW14R104S
Working Length 190 cm
Guide Wire Diameter 0.014″ (0.36 mm)
Tip Shape Straight
Tip Load 0.5 gf
Coating Hybrid Coating (Hydrophilic Shaft with Hydrophobic Tip)

Product Also Known As

ASAHI SION Blue Guide Wire, AHW14R104S Guide Wire, ASAHI SION Blue Straight Tip Guide Wire, 0.014 Inch Coronary Guide Wire, Hybrid Coated PCI Guide Wire, Coronary Intervention Guide Wire, PTCA Guide Wire
