CleverCut3V V-System Triple-Lumen Sphincterotomes 0.025 KD-V431M-0730

CleverCut3V V-System Triple-Lumen Sphincterotome is a single-use device designed for ERCP procedures. It enables precise biliary sphincterotomy while supporting smooth guidewire-assisted cannulation. The device is compatible with 0.025-inch guidewires and provides reliable control during therapeutic endoscopic procedures.

BUY NOW

SKU KD-V431M-0730 Category

The triple-lumen design features separate channels for the cutting wire, guidewire, and contrast injection, allowing efficient workflow throughout ERCP procedures. Its 30 mm cutting wire and 4.0 Fr tapered distal tip help achieve controlled sphincterotomy while maintaining stable catheter positioning. The CleverCut-coated cutting wire and pre-curved tip are designed to reduce unintended tissue injury and improve cannulation performance during electrosurgical cutting. Compatible with the Olympus V-System, the device offers dependable performance for biliary and pancreatic therapeutic interventions.

Technical Specification

Specification Details
Model Number KD-V431M-0730
Working Length 170 cm
Minimum Channel Size 2.8 mm
Compatible Guidewire 0.025 in
Distal Tip Diameter 4.0 Fr
Distal Tip Length 7 mm
Cutting Wire Length 30 mm

Product Also Known As

CleverCut3V V-System Triple-Lumen Sphincterotome, Triple-Lumen ERCP Sphincterotome, Wireguided Sphincterotome, 0.025 Inch Sphincterotome, Biliary Sphincterotomy Device, Single-Use ERCP Sphincterotome, Endoscopic Sphincterotome
