CleverCut3V Distal Wireguided triple lumen c-channel sphincterotomes – Short bend tip 0.035 KD-VC412Q-0215

CleverCut3V Distal Wireguided Triple Lumen C-Channel Sphincterotome is a single-use device designed for ERCP procedures. It supports precise biliary sphincterotomy while enabling reliable guidewire-assisted cannulation. The short bend tip design provides improved catheter control in challenging anatomical positions.

BUY NOW

SKU KD-VC412Q-0215 Category

The device features a triple-lumen c-channel design with dedicated channels for the cutting wire, guidewire, and contrast injection, allowing smooth workflow during therapeutic ERCP procedures. Its 2 mm short bend tip and 15 mm cutting wire enable compact bowing, making selective bile duct cannulation easier when the papilla is close to the endoscope. The pre-curved catheter improves catheter orientation and helps maintain stable positioning throughout sphincterotomy. Compatible with 0.035-inch guidewires, the device is intended for single-use and offers excellent fluoroscopic visibility during biliary interventions.

Technical Specification

Specification Details
Model Number KD-VC412Q-0215
Working Length 195 cm
Minimum Channel Size 3.7 mm
Compatible Guidewire 0.035 in
Distal Tip Width 4.4 Fr
Distal Tip Length 2 mm
Cutting Wire Length 15 mm

Product Also Known As

CleverCut3V Short Bend Sphincterotome, Triple Lumen C-Channel Sphincterotome, Wireguided ERCP Sphincterotome, Short Bend Tip Sphincterotome, Biliary Sphincterotomy Device, Single Use ERCP Sphincterotome, 0.035 Inch Guidewire Sphincterotome
