Asahi sion guide wire straight tip 190cm AHW14R101S

ASAHI SION Guide Wire Straight Tip AHW14R101S is a single-use hydrophilic coronary guide wire designed for navigating tortuous coronary anatomy during percutaneous coronary intervention (PCI). It features a straight 0.014″ tip with excellent torque transmission, flexibility, and trackability for reliable lesion crossing. The 190 cm working length supports routine PCI and guide catheter-based coronary interventions.

BUY NOW

SKU AHW14R101S Category

The ASAHI SION Guide Wire Straight Tip AHW14R101S is engineered to provide outstanding steerability and distal vessel access during coronary interventions. Its proprietary ACT ONE composite core technology enhances torque response, tip durability, shape retention, and resistance to whipping, while the hydrophilic spring-coil coating ensures smooth advancement through tortuous and narrowed coronary vessels. The soft 0.7 gf tip load, 28 cm spring coil, and 3 cm radiopaque segment provide excellent trackability, visualization, and atraumatic vessel navigation, making it suitable as a frontline guide wire for routine and complex PCI procedures. Supplied sterile for single-use applications, the guide wire delivers dependable clinical performance while eliminating the need for reprocessing.

Technical Specification

Specification Details
Model Number AHW14R101S
Working Length 190 cm
Guide Wire Diameter 0.014″ (0.36 mm)
Tip Shape Straight
Tip Load 0.7 gf
Coating Hydrophilic

Product Also Known As

ASAHI SION Guide Wire, AHW14R101S Guide Wire, ASAHI SION Straight Tip Guide Wire, 0.014 Inch Coronary Guide Wire, Hydrophilic PCI Guide Wire, Coronary Intervention Guide Wire, PTCA Guide Wire
