Multi-3V Plus V-System triple-lumen stone-extraction balloon 15/18/20 B-V433P-A

Multi-3V Plus V-System Triple-Lumen Stone-Extraction Balloon is a single-use device designed for ERCP stone retrieval procedures. It enables efficient extraction of biliary stones using a durable, adjustable balloon with three inflation diameters. The over-the-wire design supports stable guidewire access and smooth stone extraction during therapeutic ERCP procedures.

BUY NOW

SKU B-V433P-A Category

The Multi-3V Plus V-System features a triple-lumen catheter that allows simultaneous guidewire access, contrast injection, and balloon inflation, reducing the need for multiple device exchanges during ERCP. Its high-strength latex balloon inflates to three selectable diameters of 15 mm, 18 mm, and 20 mm, providing flexibility for extracting stones from dilated bile ducts. The over-the-wire sheath design maintains excellent guidewire stability, while dual radiopaque markers enhance fluoroscopic visualization for accurate balloon positioning. This model features an injection port positioned above the balloon, improving procedural versatility while delivering reliable performance during biliary stone retrieval.

Technical Specification

Specification Details
Model Number B-V433P-A
Working Length 190 cm
Minimum Channel Size 3.2 mm
Compatible Guidewire 0.035 in
Balloon Diameter 15 / 18 / 20 mm
Injection Port Above Balloon
Sheath Design Over-the-Wire
Lumen Configuration Triple Lumen

Product Also Known As

Multi-3V Plus Stone Extraction Balloon, V-System Triple-Lumen Balloon, ERCP Stone Retrieval Balloon, Over-the-Wire Extraction Balloon, Biliary Stone Extraction Balloon, Triple-Lumen ERCP Balloon Catheter, Endoscopic Stone Retrieval Balloon
