Medtronic Laucher Guiding catheter 6 Fr – 100 cm Amaplatz Left AL1.0 LA6AL10
The Medtronic Launcher Guiding Catheter is a sterile, single-use catheter used in coronary procedures. It is designed to facilitate the delivery of guidewires, balloons, and stents into the left coronary artery. This device provides optimal flexibility, reliable support, and excellent radiopacity.
The AL 1.0 curve is shaped to provide strong backup support and enhanced engagement of the left coronary ostium. Its Full‑Wall shaft construction with encapsulated flat‑wire braid ensures superior torque control, kink resistance, and consistent shape retention during procedures. The 0.071‑inch inner lumen supports efficient contrast injection and seamless passage of interventional tool. A Nylon outer jacket and radiopaque marker band offer clear hub-to-tip visibility under fluoroscopy for accurate positioning.
Technical Specification:
| Specification | Details |
|---|---|
| Outer diameter | 6 Fr (≈2 mm) |
| Inner diameter (ID) | 0.071 in |
| Length | 100 cm |
| Curve type | Amplatz Left AL 1.0 |
| Shaft construction | Full‑Wall shaft with encapsulated flat‑wire braid |
| Radiopacity | Nylon outer jacket + radiopaque marker band |
Product Also Knows As:
Medtronic Launcher AL1.0 6Fr guiding catheter, Launcher LA6AL10 coronary catheter, 6 Fr AL 1.0 Launcher catheter, 100 cm Amplatz Left guide catheter, Coronary guide catheter AL1.0 6Fr
