Conmed Sentinel Drill Bits 7.5mm dia. S8575
The Sentinel Drill Bit 7.5 mm (CAT # S8575) is a sterile, single-use cannulated orthopedic drill bit designed for creating precision bone tunnels during ligament reconstruction procedures. It features a 7.5 mm diameter and a working length of 229 mm. Engineered for accurate femoral or tibial tunnel preparation, it supports both anatomic and minimally invasive surgical techniques.
This Sentinel Drill Bit 7.5 mm (S8575) is part of the advanced Sentinel series aimed at enhancing safety and precision in ACL/PCL reconstruction surgeries. Its mono-fluted, cannulated design allows use over a 2.4 mm guide pin, while the 270° smooth shaft surface helps protect the medial femoral condyle during medial-portal drilling approaches. The drill is marked with depth graduations, promoting consistent and controlled tunnel creation, and is delivered sterile for single-use to maintain optimal performance and reduce cross-contamination risk. With its 7.5 mm diameter specifically designed for certain graft sizes or fixation systems, this instrument supports surgeons in achieving precise bone preparation and reliable reconstruction outcomes.
Technical Specification
| Specification | Details |
|---|---|
| Catalog Number | S8575 |
| Diameter | 7.50 mm |
| Length | 229.0 mm (≈9″) |
| Design | Mono-fluted, cannulated; 270° smooth shaft surface for condyle protection |
| Usage | Bone tunnel drilling for ACL/PCL reconstruction (femoral/tibial) |
| Sterility & Use | Sterile, single-use device |
Product Also Known As
Sentinel Drill Bit 7.5 mm, S8575 Drill Bit 7.5 mm, Sentinel 7.5 mm Cannulated Drill Bit, ConMed Sentinel S8575, Sentinel Bone Tunnel Drill Bit 7.5 mm
