Conmed Guardsman Interference Screws Taper-Tip 9mm x 30mm, 3.5mm Hex C8928
The Guardsman Interference Screw C8928 is a 9 mm × 30 mm, taper-tip, titanium alloy interference screw intended for femoral graft fixation in knee ligament reconstruction. It incorporates a 3.5 mm hex drive for precise insertion. It stabilizes the graft while protecting it at the intra-articular tunnel entrance.
The taper-tip of the Guardsman C8928 eases initial engagement into the bone tunnel, reducing insertion resistance. Its thread design is optimized to minimize graft abrasion and evenly distribute compressive forces. The rounded head assists in gently pressing the graft into the tunnel and reducing the risk of slippage. Over time, the implant provides stable mechanical fixation to support graft integration with surrounding bone.
Technical Specification
| Specification | Details |
|---|---|
| Length | 30 mm |
| Diameter | 9 mm |
| Drive Type | 3.5 mm Hex |
| Tip Type | Taper-Tip |
| Material | Titanium alloy (per ASTM F-136) |
Product Also Known As
Guardsman C8928 Interference Screw, ConMed C8928, 9 × 30 mm Taper-Tip Interference Screw, Titanium Taper-Tip Interference Screw 9 mm × 30 mm, Femoral Taper-Tip Fixation Screw
