Conmed Graft Preparation Table PS8820
The Graft Preparation Table PS8820 is a specialized surgical instrument platform designed for preparing tendon or bone-tendon grafts in reconstructive procedures. It provides a secure working surface and permits precise measurement, tensioning and sizing of grafts prior to fixation. The table is used in orthopedic graft preparation workflows such as ACL or PCL reconstruction.
The Graft Preparation Table PS8820 supports multiple graft preparation steps by allowing surgeons to clean, whip-stitch, measure, and pre-tension soft tissue or bone-tendon grafts with ease. Its modular construction enables rapid interchange of clamps, sizing blocks and fixation device holders to match different graft types and diameters. The table’s design ensures reproducible graft preparation by incorporating features such as etched tension scale and a sizing block that fits grafts from 3.0 mm to 13 mm in diameter. By providing a stable and organized platform, it helps reduce operative time and improve consistency of graft constructs.
Technical Specification
| Specification | Detail |
|---|---|
| Compatible graft diameters | 3.0 mm to 13 mm (in 0.5 mm increments) |
| Maximum graft tension | 30 lbs / 120 N (for tension clamp) |
| Table platform dimensions | 17-5/8″ × 9-1/8″ × 1″ |
| Slide locks | Universal slide locks with spring-loaded locking button for one‐hand operation |
| Modularity | Interchangeable components (clamps, sizing block, tensioner) |
Product Also Known As
Graft Preparation Table PS 8820, Concept GraFix Graft Prep Table, CONMED PS8820 Graft Preparation Table, Grafix Graft Prep Bench PS8820, ACL/PCL graft prep table, Graft prep workstation PS8820
