Boston Scientific UroMax Ultra High Pressure Balloon Catheter M0062251030
The UroMax Ultra™ catheter is a sterile, single-use high-pressure balloon dilator featuring a 21 Fr (≈ 7 mm) non-compliant balloon that is 4 cm long mounted on a 5.8 Fr (~1.9 mm) shaft with a 75 cm usable length. It incorporates HydroPlus™ coating and quadra‑fold technology for a compact insertion profile. Designed to relieve urinary–tract strictures with controlled radial expansion up to 20 atm.
This non-compliant balloon maintains consistent diameter under high pressure, concentrating dilation force precisely on ureteral strictures without overexpansion to adjacent tissue. HydroPlus™ coating and quadra‑fold design minimize the balloon profile, easing navigation through narrow or tortuous anatomy . A kink-resistant shaft, tapered distal tip, and radiopaque marker bands improve positioning and safety under fluoroscopy. Dual-lumen hubs allow simultaneous inflation and contrast injection, enhancing procedural control.
Technical Specification
| Specification | Details |
|---|---|
| Inflated Balloon Diameter | 21 Fr (~7.0 mm) |
| Balloon Length | 4 cm |
| Shaft Size & Usable Length | 5.8 Fr (~1.9 mm); 75 cm |
| Maximum Inflation Pressure | Up to 20 atm |
| Coating & Design | HydroPlus™ coating, quadra‑fold, non‑compliant |
| Marker Bands & Tips | Radiopaque markers; tapered distal tip |
| Hubs | Dual‑lumen for inflation + contrast injection |
Product Also Knows As
UroMax Ultra 21 Fr × 4 cm balloon catheter, M0062251030 ureteral high-pressure dilator, HydroPlus UroMax 21F 4 cm balloon, quadra-fold UroMax Ultra dilator
